Let’s begin with Lecture 17 of the HTML5 & CSS3 series. Understanding the CSS Box Model – Margin, Padding, Border. This lecture is for absolute beginners; even kids can follow along and understand.
🎯 Objective:
By the end of this lecture, you will:
- Understand what the CSS Box Model is
- Know how
margin,padding, andborderwork together - Be able to control spacing around elements
- Style a card layout using the box model
- Make your webpage look neat and well-spaced!
📦 What Is the Box Model?
Every element on a webpage is a box. The Box Model helps us understand how space is calculated for each box.
Think of it like this:
Imagine wrapping a gift — the present is the content, the wrapping paper is padding, the box is the border, and the space between boxes is margin.
🔍 The Four Parts of the Box Model
| Part | Description |
|---|---|
| Content | The actual text or image inside the box |
| Padding | Space between content and border (inside the box) |
| Border | Line that wraps around the padding and content |
| Margin | Space outside the border, between elements |
Visual structure:
+----------------------------+
| Margin |
| +------------------+ |
| | Border | |
| | +------------+ | |
| | | Padding | | |
| | | +--------+ | | |
| | | |Content | | | |
| | | +--------+ | | |
| | +------------+ | |
| +------------------+ |
+----------------------------+📏 How It Affects Size
If you set:
div {
width: 200px;
padding: 20px;
border: 5px solid black;
margin: 10px;
}The total width becomes:
200px (content) + 40px (left & right padding) + 10px (left & right border) = 250pxMargin doesn’t affect the size of the box itself, but it affects spacing from other elements.
🖌️ Using Margin, Padding, and Border
margin
Controls space outside the element.
margin: 10px; /* all sides */
margin: 10px 20px; /* top/bottom, left/right */
margin: 10px auto; /* center an element horizontally */padding
Controls space inside the element, between content and border.
padding: 15px;
padding: 10px 20px 10px 20px; /* top, right, bottom, left */border
Adds a line around the element.
border: 2px solid red;
border-top: 1px dashed blue;💻 Try This: Build a Simple Card Layout
Let’s create a new HTML file that shows off a styled card using the box model.
Step 1: Create a New File
In your VS Code project folder (MyFirstWebsite), create a new file named:
card-layout.htmlStep 2: Add This Code
<!DOCTYPE html>
<html>
<head>
<title>CSS Box Model</title>
<style>
body {
background-color: #f9f9f9;
font-family: Arial, sans-serif;
padding: 40px;
}
.card {
width: 300px;
background-color: white;
padding: 20px;
border: 2px solid #ddd;
margin: 20px auto;
box-shadow: 0 4px 8px rgba(0,0,0,0.1);
}
.card h2 {
margin-top: 0;
}
.card p {
margin-bottom: 0;
}
</style>
</head>
<body>
<h1>My First Card</h1>
<div class="card">
<h2>Hello, World!</h2>
<p>This is a simple card made using CSS box model properties.</p>
</div>
<div class="card">
<h2>Welcome to My Site</h2>
<p>I'm learning about margins, padding, and borders. It's fun!</p>
</div>
<p><a href="index.html">Back to Home</a></p>
</body>
</html>Step 3: Run with Live Server
Right-click the code → Show All Commands → Launch Live Server
🎉 You’ve built a clean, centered card layout using margin, padding, and border!
🧪 Try It Yourself!
- Increase the padding of one card and see how it affects the layout.
- Give one card a different border color and thickness.
- Use
margin: 0 autoto center another element on the page. - Try removing the border from one card and notice the difference.
🚀 Next Lecture Preview:
In Lecture 18, we’ll learn how to control element display types, including block, inline, and inline-block — So you can decide how elements behave and interact on your page!
